The new PEAK SIP7 DC/DC voltage converter features a dual output with high 5000 VAC isolation, designed for a maximum working voltage of 300 Vrms. It is ideally suited for IGBT and SiC applications where fast switching times are required. In addition to overvoltage, undervoltage, and overload protection, the converter features continuous short-circuit protection and an efficiency of 86%.
The new PEAK SIP7 DC/DC voltage converter features a dual output with high 5000 VAC isolation, designed for a maximum working voltage of 300 Vrms. It is ideally suited for IGBT and SiC applications where fast switching times are required. In addition to overvoltage, undervoltage, and overload protection, the converter features continuous short-circuit protection and an efficiency of 86%.
The new ultra-compact PEAK 25W AC/DC voltage converter with 4200
VAC isolation measures 70x48x23 mm and includes a trim function
(output voltage ±10%). The input voltage range is from 85 to 305 VAC or
100 to 430 VDC with overload and overvoltage protection and an
efficiency of up to 82%.
The new PEAK voltage converter 2X-S7U-151509ZBH5 features at 15V input voltage into the combination of the output voltages +15V / -8.7V. (other models on request). The high isolation voltage is 5000VAC with very low insulation capacitance of approx. 5pF, continuous short-circuit protection with auto-recovery function, an efficiency of 80% and low output ripple.
The 6 Watt DC/DC voltage converter from PEAK electronics in the SIP8 case converts input voltages of 5V, 12V, 24V and 48V into output voltages of 3.3V, 5V, 9V, 12V, 15 and 24V, with an optional 2:1 or 4:1 input voltage range.
The operating temperature is between -40°C and +95°C. The P(C)26NG has continuous short-circuit protection, standard 1.5kV isolation and an efficiency rate of up to 88%. It is optionally available with additional REMOTE CONTROL and higher isolation (3kV) in single and dual versions.
New modified switching regulators PSR1M-24xxS & PSR2M-xxxxS – 1A and 2A output current in SIP3 Case
PEAK SBC-POWER Solutions: DIN RAIL DC/DC converter with 20 watts
P10AU-xxxxELF – 2 Watt DC/DC Power Converter
10C-1X1R-xxxxE4:1MC – 10 Watt DC/DC Power Converter
6-D24R-xxxxE2:1MC – 6 Watt DC/DC Power Converter
